FIAT Ducato 2026 Model Type B Emergency Ambulance

TSE & EN 1789 Compliant High-Performance Emergency Medical & Inter-Hospital Patient Transport Vehicle

🌟 Engineering & Operational Highlights

  • TSE & EN 1789 Certified Platform: Type B Emergency Ambulance fully tested and certified for EN 1789 standards (10g crash testing, EMC compliance, noise reduction, and fire safety).
  • Ergonomic Cabin Architecture: High-roof internal design offering 5+1 seating and patient capacity for optimal paramedic workspace.
  • Hygienic Interior Fit-Out: Washable ABS/PVC wall panels paired with an 18mm marine-grade plywood anti-static, anti-slip vinyl subfloor.
  • Integrated Medical Oxygen Grid: Dual 10L steel oxygen cylinder setup with central wall outlets, high-pressure regulators, and precision flowmeters.
  • Climate & Power Automation: Safkar rooftop A/C system, Eberspächer auxiliary cabin heater, Victron/ICU 12V-220V inverter/rectifier, and dual battery grid.

⚙️ 1. Drivetrain, Chassis & Mechanical Performance

Engineering ParameterTechnical Specification & Values
Base Chassis & ApprovalFIAT Ducato (Type: 250, Variant: DF6FC, Version: 2L0031) | M1 Emergency Ambulance
Type Approval CertificateTSE Ambulance Compliance Certificate (AUB No: 20.10.03/TSE-0001-67124-6061-0)
Seating Capacity5 + 1 Persons (Driver, Medical Crew & Patient Capacity)
Weight & Payload RatingsCurb Weight: 2,915 kg | Payload: 585 kg | Gross Vehicle Weight (GVW): 3,500 kg
Braking & Safety SystemsABS, ESP/VSC, Hill-Start Assist, Driver Airbag, Front & Rear Disc Brakes

🚑 2. Patient Compartment Architecture & Interior Infrastructure

Structural ComponentMaterial, Build Standard & Engineering Detail
Bulkhead PartitionHeavy-duty PVC/ABS Bulkhead Partition with sliding communication glass window
Thermal & Acoustic InsulationEN 1789 standard self-extinguishing polyurethane acoustic and thermal insulation barrier
Subfloor & Surface Finish18 mm Marine-grade water-resistant plywood subfloor with heavy-duty anti-slip vinyl coating
Medical Cabinetry ModulesTSE 10g crash-tested lightweight PVC cabinet units with safety locks and equipment shelves
Attendant & Crew Seating10g-tested doctor/attendant seat (360° swivel capability) + side squad bench with under-seat storage
Airflow & Ventilation GridBi-directional roof ventilation extraction/intake fan grid

🔌 3. Electrical Systems, Climate Control & Emergency Hardware

System Sub-UnitTechnical Configuration
Power Inverter & RectifierVictron / ICU Power 12V-220V Pure Sine-Wave Inverter & Automatic Battery Charger
External Shoreline Outlet220V Exterior Shoreline Mains Inlet Connection with auto-eject start feature and connection cable
Control Panel & DistributionDigital/Touch switch panel with circuit breakers, dual battery isolator, 220V AC & 12V DC sockets
HVAC & Auxiliary HeatingSafkar high-capacity rooftop AC unit + Eberspächer Airtronic independent diesel cabin heater
Emergency Signaling & AudioAerodynamic LED roof lightbar, perimeter strobe lights, rear beacon lights, alley lights & multi-tone siren
Internal Lighting SystemFlush ceiling LED panel lights, trauma illumination mode & flexible spotlight for patient examination

🩺 4. Medical Equipment & Patient Support Matrix

Equipment DescriptionSpecification / StandardOperational Capabilities
Main Stretcher SystemAutomatic Loading StretcherHeavy-duty roll-in self-loading main stretcher with locking base platform
Chair StretcherFoldable Chair StretcherStairway transfer chair stretcher with quick-release wall bracket storage
Scoop StretcherAluminum Scoop StretcherAdjustable length split-frame stretcher for trauma patient immobilization
Immobilization SetVacuum Mattress & Spine BoardFull-body vacuum mattress, HDPE spine board, and cervical collar immobilizer set
Defibrillator UnitMonitor Defibrillator / AEDBiphasic defibrillator monitor with ECG tracking, AED mode, and recorder
Transport VentilatorPortable Emergency VentilatorPneumatic/Electric transport ventilator for artificial patient respiration
Suction UnitPortable Suction MachineHigh-vacuum electric aspirator unit with wall charging base
Infusion SystemVolumetric Infusion PumpPrecision micro-dosing fluid and drug delivery infusion pump
Oxygen Pipeline Grid2x 10L Steel Tanks + OutletsCentral oxygen distribution network with dual regulators, flowmeters, and humidifiers

* Technical specifications are based on standard 2026 Model FIAT Ducato Type B Emergency Ambulance conversions. Medical layout and equipment configurations can be customized based on project specifications.

“`
